CALD1 Monoclonal antibody

• Featured Product
• KD/KO Validated

CALD1 Monoclonal Antibody for WB, IHC, IF/ICC, FC (Intra), ELISA

Host / Isotype

Mouse / IgG2b

Reactivity

human, mouse, rat

Applications

WB, IHC, IF/ICC, FC (Intra), ELISA

Conjugate

Unconjugated

Publications

2

CloneNo.

1E1C11

Cat no : 66693-1-Ig

Synonyms

Caldesmon, CDM, caldesmon 1, CAD, 1E1C11

---

Validation Data Gallery

•

  WB analysis using 66693-1-Ig

  Various lysates were subjected to SDS PAGE followed by western blot with 66693-1-Ig (CALD1 antibody) at dilution of 1:10000 incubated at room temperature for 1.5 hours.

•

  WB analysis of HeLa using 66693-1-Ig

  WB result of CALD1 antibody (66693-1-Ig; 1:50000; incubated at room temperature for 1.5 hours) with sh-Control and sh-CALD1 transfected HeLa cells.

•

  WB analysis using 66693-1-Ig

  Various lysates were subjected to SDS PAGE followed by western blot with 66693-1-Ig (CALD1 antibody) at dilution of 1:20000 incubated at room temperature for 1.5 hours.

•

  IHC staining of human colon cancer using 66693-1-Ig

  Immunohistochemical analysis of paraffin-embedded human colon cancer tissue slide using 66693-1-Ig (CALD1 antibody) at dilution of 1:4000 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of human colon cancer using 66693-1-Ig

  Immunohistochemical analysis of paraffin-embedded human colon cancer tissue slide using 66693-1-Ig (CALD1 antibody) at dilution of 1:4000 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of human hysteromyoma using 66693-1-Ig

  Immunohistochemical analysis of paraffin-embedded human hysteromyoma tissue slide using 66693-1-Ig (CALD1 antibody) at dilution of 1:500 (under 40x lens. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of human hysteromyoma using 66693-1-Ig

  Immunohistochemical analysis of paraffin-embedded human hysteromyoma tissue slide using 66693-1-Ig (CALD1 antibody) at dilution of 1:500 (under 10x lens. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of mouse colon using 66693-1-Ig

  Immunohistochemical analysis of paraffin-embedded mouse colon tissue slide using 66693-1-Ig (CALD1 antibody) at dilution of 1:4000 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of mouse colon using 66693-1-Ig

  Immunohistochemical analysis of paraffin-embedded mouse colon tissue slide using 66693-1-Ig (CALD1 antibody) at dilution of 1:4000 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IF Staining of HeLa using 66693-1-Ig

  Immunofluorescent analysis of (4% PFA) fixed HeLa cells using CALD1 antibody (66693-1-Ig, Clone: 1E1C11 ) at dilution of 1:400 and CoraLite®488-Conjugated Goat Anti-Mouse IgG(H+L).

•

  IF Staining of HepG2 using 66693-1-Ig

  Immunofluorescent analysis of (-20°C Methanol) fixed HepG2 cells using CALD1 antibody (66693-1-Ig, Clone: 1E1C11 ) at dilution of 1:400 and CoraLite®488-Conjugated Goat Anti-Mouse IgG(H+L).

•

  FC experiment of HeLa using 66693-1-Ig

  1X10^6 HeLa cells were intracellularly stained with 0.4 ug Anti-Human CALD1 (66693-1-Ig, Clone:1E1C11) and CoraLite®488-Conjugated Goat Anti-Mouse IgG(H+L) at dilution 1:1000 (red), or 0.4 ug Mouse IgG2b Isotype Control (MPC-11) (65128-1-Ig, Clone: MPC-11) (blue). Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C).

---

Tested Applications

• Positive WB detected in: NCI-H1299 cells, HeLa cells, U2OS cells, HepG2 cells, PC-3 cells, SKOV-3 cells, A2780 cells, HSC-T6 cells, NIH/3T3 cells, 4T1 cells, Calu-1 cells, Caco-2 cells, Caki-1 cells, MCF-10A cells, LNCaP cells, SK-N-SH cells
• Positive IHC detected in: human colon cancer tissue, human hysteromyoma tissue, mouse colon tissue; Note: suggested antigen retrieval with TE buffer pH 9.0; (*) Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0
• Positive IF/ICC detected in: HepG2 cells, HeLa cells
• Positive FC (Intra) detected in: HeLa cells

Recommended dilution

• Western Blot (WB): WB : 1:2000-1:10000
• Immunohistochemistry (IHC): IHC : 1:2000-1:8000
• Immunofluorescence (IF)/ICC: IF/ICC : 1:200-1:800
• Flow Cytometry (FC) (INTRA): FC (INTRA) : 0.40 ug per 10^6 cells in a 100 µl suspension

It is recommended that this reagent should be titrated in each testing system to obtain optimal results.

Sample-dependent, Check data in validation data gallery.

Published Applications

• WB: See 1 publications below
• IF: See 1 publications below

Product Information

66693-1-Ig targets CALD1 in WB, IHC, IF/ICC, FC (Intra), ELISA applications and shows reactivity with human, mouse, rat samples.

• Tested Reactivity: human, mouse, rat
• Cited Reactivity: human
• Host / Isotype: Mouse / IgG2b
• Class: Monoclonal
• Type: Antibody
• Immunogen: CALD1 fusion protein Ag13676
• Full Name: caldesmon 1
• Calculated Molecular Weight: 538 aa, 63 kDa
• Observed Molecular Weight: 70 kDa~75 kDa
• GenBank Accession Number: BC040354
• Gene Symbol: CALD1
• Gene ID (NCBI): 800
• RRID: AB_2882047
• Conjugate: Unconjugated
• Form: Liquid
• Purification Method: Protein A purification
• Storage Buffer: PBS with 0.02% sodium azide and 50% glycerol pH 7.3.
• Storage Conditions: Store at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20^oC storage. 20ul sizes contain 0.1% BSA.

Publications

Species	Application	Title
human	IF	Int J Mol Sci; Changes in the Expression of Smooth Muscle Cell-Related Genes in Human Dermal Sheath Cup Cells Associated with the Treatment Outcome of Autologous Cell-Based Therapy for Male and Female Pattern Hair Loss.; Authors - Yuzo Yoshida
human	WB	Int J Clin Pract; GPX3-Mediated Oxidative Stress Affects Pyrimidine Metabolism Levels in Stomach Adenocarcinoma via the AMPK/mTOR Pathway; Authors - Yaowen Zhang
