ARL13B Monoclonal antibody

ARL13B Monoclonal Antibody for WB, IF/ICC, IF-Fro, ELISA

Host / Isotype

Mouse / IgG2a

Reactivity

human, mouse, pig, canine and More (1)

Applications

WB, IHC, IF/ICC, IF-Fro, ELISA

Conjugate

Unconjugated

Publications

21

CloneNo.

1H6C3

Reviews (3)

Cat no : 66739-1-Ig

Synonyms

ARL2-like protein 1, ARL2L1, ARL2 like protein 1, ADP-ribosylation factor-like protein 2-like 1, ADP-ribosylation factor-like protein 13B

---

Validation Data Gallery

•

  WB analysis of HepG2 using 66739-1-Ig

  HepG2 cells were subjected to SDS PAGE followed by western blot with 66739-1-Ig (ARL13B antibody) at dilution of 1:3000 incubated at room temperature for 1.5 hours.

•

  WB analysis of HEK-293 using 66739-1-Ig

  HEK-293 cells were subjected to SDS PAGE followed by western blot with 66739-1-Ig (ARL13B antibody) at dilution of 1:3000 incubated at room temperature for 1.5 hours.

•

  WB analysis of NCCIT using 66739-1-Ig

  NCCIT cell were subjected to SDS PAGE followed by western blot with 66739-1-Ig (ARL13B antibody) at dilution of 1:3000 incubated at room temperature for 1.5 hours.

•

  IF Staining of mouse heart using 66739-1-Ig

  rozen tissue section of embryonic mouse heart (E12.5) was stained for cardiac troponin-T /cTnT (red, Cat. No 15513-1-AP), CD31/PECAM-1 (magenta), and Arl13B (green, Cat. No 66739-1-Ig) with DAPI as a counterstain for visualizing the nucleus (blue). cTnT stains cardiomyocytes and was visualized with an Alexa Fluor 555 secondary antibody. CD31 stains endocardial/endothelial cells and was visualized with an Alexa Fluor 647 secondary antibody. Arl13B stains primary cilia and was visualized with an Alexa Fluor 488 secondary antibody. The Image and figure legends are intellectual property of @LAF_in_the_LAB.

•

  IF Staining of mouse heart using 66739-1-Ig

  Frozen tissue section of embryonic mouse heart (E12.5) was stained for cardiac troponin-T/cTnT (magenta, Cat. No 15513-1-AP), CD31/PECAM-1 (white), and Arl13B (yellow, Cat. No 66739-1-Ig) with DAPI as a counterstain for visualizing the nucleus (cyan). cTnT stains cardiomyocytes and was visualized with an Alexa Fluor 555 secondary antibody and psedocolored to magenta.CD31 stains endocardial/endothelial cells and was visualized with an Alexa Fluor 647 secondary antibody and psedocolored to white. Arl13B stains primary cilia and was visualized with an Alexa Fluor 488 secondary antibody and psedocolored to yellow. The Image and figure legends are intellectual property of @LAF_in_the_LAB.

•

  IF Staining of hTERT-RPE1 using 66739-1-Ig

  Immunofluorescent analysis of (-20°C Methanol) fixed hTERT-RPE1 cells using ARL13B antibody (66739-1-Ig, Clone: 1H6C3 ) at dilution of 1:800 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L), ARL13B antibody (17711-1-AP, red).

---

Tested Applications

• Positive WB detected in: HepG2 cells, HEK-293 cells, NCCIT cell
• Positive IF-Fro detected in: mouse heart tissue
• Positive IF/ICC detected in: hTERT-RPE1 cells

Recommended dilution

• Western Blot (WB): WB : 1:1000-1:6000
• Immunofluorescence (IF)-FRO: IF-FRO : 1:50-1:500
• Immunofluorescence (IF)/ICC: IF/ICC : 1:400-1:1600

It is recommended that this reagent should be titrated in each testing system to obtain optimal results.

Sample-dependent, Check data in validation data gallery.

Published Applications

• WB: See 4 publications below
• IHC: See 1 publications below
• IF: See 19 publications below

Product Information

66739-1-Ig targets ARL13B in WB, IHC, IF/ICC, IF-Fro, ELISA applications and shows reactivity with human, mouse, pig, canine samples.

• Tested Reactivity: human, mouse, pig, canine
• Cited Reactivity: human, mouse, rat
• Host / Isotype: Mouse / IgG2a
• Class: Monoclonal
• Type: Antibody
• Immunogen: ARL13B fusion protein Ag12031
• Full Name: ADP-ribosylation factor-like 13B
• Calculated Molecular Weight: 48 kDa
• Observed Molecular Weight: 60 kDa
• GenBank Accession Number: BC094725
• Gene Symbol: ARL13B
• Gene ID (NCBI): 200894
• RRID: AB_2882088
• Conjugate: Unconjugated
• Form: Liquid
• Purification Method: Protein A purification
• Storage Buffer: PBS with 0.02% sodium azide and 50% glycerol pH 7.3.
• Storage Conditions: Store at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20^oC storage. 20ul sizes contain 0.1% BSA.

Background Information

ARL13B, also named as ARL2L1, is a small ciliary G protein of the Ras superfamily. Localized in the cilia, it is required for cilium biogenesis and sonic hedgehog signaling. Defects in ARL13B are the cause of Joubert syndrome (JS) which is an autosomal recessive disorder characterized by a distinctive cerebellar malformation (PMID: 19906870). Arl13b is predicted to be a 48 kDa protein, and the 60 kDa band is likely to represent a modified form of Arl13b. ARL13B can be used to mark the cilia (PMID:22072986).

Publications

Species	Application	Title
human	IF,WB	Nat Commun; INTS13 variants causing a recessive developmental ciliopathy disrupt assembly of the Integrator complex; Authors - Lauren G. Mascibroda
human	WB	Elife; Multiple ciliary localization signals control INPP5E ciliary targeting; Authors - Dario Cilleros-Rodriguez
human	IF	Sci Rep; Targeted exon skipping rescues ciliary protein composition defects in Joubert syndrome patient fibroblasts.; Authors - Elisa Molinari
rat	IF	eNeuro; CCP1, a Tubulin Deglutamylase, Increases Survival of Rodent Spinal Cord Neurons following Glutamate-Induced Excitotoxicity.; Authors - Yasmin H Ramadan
human	IF	PLoS One; Embryonic and foetal expression patterns of the ciliopathy gene CEP164.; Authors - L A Devlin
mouse	IF	Life Sci Alliance; HTR6 and SSTR3 ciliary targeting relies on both IC3 loops and C-terminal tails.; Authors - Pablo Barbeito

Reviews

The reviews below have been submitted by verified Proteintech customers who received an incentive for providing their feedback.

---

FH

Lindsey (Verified Customer) (05-24-2021)

I much prefer the Rabbit polyclonal ARL13B (Cat#17711-I-AP) but it is really nice to have an Arl13B Mouse monoclonal for use in co-stains with other targets. I wish it didn't have to be used at such a high working concentration!

• Applications: Immunohistochemistry, Immunofluorescence
• Primary Antibody Dilution: 1:50
• Cell Tissue Type: Human kidney (FFPE)

ARL13B Antibody Immunohistochemistry,Immunofluorescence validation (1:50 dilution) in Human kidney (FFPE) (Cat no:66739-1-Ig)

FH

Feng-Qian (Verified Customer) (04-04-2019)

This antibody works for detecting primary cilia in MEFs with low background. The intensity is lower than the Arl13B rabbit antibody (17711-1-AP) in general but specific.

• Applications: Immunofluorescence,
• Primary Antibody Dilution: 1:300
• Cell Tissue Type: methanol fixed Mouse embryonic fibroblasts

FH

Francesc (Verified Customer) (11-07-2018)

This antibody works beautifully, staining cilia with high intensity and specificity, as expected for ARL13B.The staining with 66739-1-Ig appears as good as that obtained with the highly validated Proteintech's rabbit anti-ARL13B (17711-1-AP).This mouse anti-ARL13B makes for a great ciliary marker.

• Applications: Immunofluorescence,
• Primary Antibody Dilution: 1:100
• Cell Tissue Type: IMCD3 cells (mouse kidney cell line)

ARL13B Antibody Immunofluorescence, validation (1:100 dilution) in IMCD3 cells (mouse kidney cell line) (Cat no:66739-1-Ig)
