Tim23 Recombinant antibody

Tim23 Uni-rAb^TM Recombinant Antibody for WB, IHC, IF/ICC, IP, ELISA

Host / Isotype

Rabbit / IgG

Reactivity

Human, mouse, rat

Applications

WB, IHC, IF/ICC, IP, ELISA

Conjugate

Unconjugated

CloneNo.

1H16

Cat no : 82540-1-RR

Synonyms

TIMM23, TIMM 23, Mitochondrial import inner membrane translocase subunit Tim23, 1H16

---

Validation Data Gallery

•

  WB analysis using 82540-1-RR

  Various lysates were subjected to SDS PAGE followed by western blot with 82540-1-RR (Tim23 antibody) at dilution of 1:5000 incubated at room temperature for 1.5 hours.

•

  IP experiment of HeLa using 82540-1-RR

  IP result of anti-Tim23 (IP:82540-1-RR, 4ug; Detection:82540-1-RR 1:1000) with HeLa cells lysate 1280 ug.

•

  IHC staining of mouse heart using 82540-1-RR

  Immunohistochemical analysis of paraffin-embedded mouse heart tissue slide using 82540-1-RR (Tim23 antibody) at dilution of 1:200 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of mouse heart using 82540-1-RR

  Immunohistochemical analysis of paraffin-embedded mouse heart tissue slide using 82540-1-RR (Tim23 antibody) at dilution of 1:200 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IF Staining of HepG2 using 82540-1-RR

  Immunofluorescent analysis of (4% PFA) fixed HepG2 cells using Tim23 antibody (82540-1-RR, Clone: 1H16 ) at dilution of 1:500 and CoraLite®488-Conjugated Goat Anti-Rabbit IgG(H+L), CL594-Phalloidin (red).

•

  Affinity and Kinetic Characterization of 82540-1-RR

  Biolayer interferometry (BLl) kinetic assays of 82540-1-RR against Human Tim23 were performed. The affinity constant is below 1 pM.

---

Tested Applications

• Positive WB detected in: HeLa cells, MCF-7 cells, Jurkat cells, K-562 cells, NIH/3T3 cells, mouse heart tissue, rat heart tissue
• Positive IP detected in: HeLa cells
• Positive IHC detected in: mouse heart tissue; Note: suggested antigen retrieval with TE buffer pH 9.0; (*) Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0
• Positive IF/ICC detected in: HepG2 cells

Recommended dilution

• Western Blot (WB): WB : 1:2000-1:10000
• Immunoprecipitation (IP): IP : 0.5-4.0 ug for 1.0-3.0 mg of total protein lysate
• Immunohistochemistry (IHC): IHC : 1:50-1:500
• Immunofluorescence (IF)/ICC: IF/ICC : 1:400-1:1600

It is recommended that this reagent should be titrated in each testing system to obtain optimal results.

Sample-dependent, Check data in validation data gallery.

Product Information

82540-1-RR targets Tim23 in WB, IHC, IF/ICC, IP, ELISA applications and shows reactivity with Human, mouse, rat samples.

• Tested Reactivity: Human, mouse, rat
• Host / Isotype: Rabbit / IgG
• Class: Recombinant
• Type: Antibody
• Immunogen: Tim23 fusion protein Ag1620
• Full Name: translocase of inner mitochondrial membrane 23 homolog (yeast)
• Calculated Molecular Weight: 22 kDa
• Observed Molecular Weight: 22 kDa
• GenBank Accession Number: BC062707
• Gene Symbol: Tim23
• Gene ID (NCBI): 10431
• Conjugate: Unconjugated
• Form: Liquid
• Purification Method: Protein A purification
• Storage Buffer: PBS with 0.02% sodium azide and 50% glycerol pH 7.3.
• Storage Conditions: Store at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20^oC storage. 20ul sizes contain 0.1% BSA.

Background Information

Tim23, a key component of the mitochondrial preprotein translocase, is anchored in the inner membrane by its C-terminal domain and exposes an intermediate domain in the intermembrane space that functions as a presequence receptor. Tim23 is the main component of the translocation channel of the TIM23 complex. (PMID: 10830167, PMID: 25083920)
