TMP21 Monoclonal antibody

TMP21 Monoclonal Antibody for WB, IHC, IF/ICC, FC (Intra), ELISA

Host / Isotype

Mouse / IgG2b

Reactivity

human, mouse, rat, pig

Applications

WB, IHC, IF/ICC, FC (Intra), ELISA

Conjugate

Unconjugated

CloneNo.

3B11F9

Cat no : 67876-1-Ig

Synonyms

TMED10, Protein TMED10, p24delta1, p24 family protein delta-1, p23

---

Validation Data Gallery

•

  WB analysis using 67876-1-Ig

  Various lysates were subjected to SDS PAGE followed by western blot with 67876-1-Ig (TMP21 antibody) at dilution of 1:20000 incubated at room temperature for 1.5 hours. The membrane was stripped and reblotted with HRP-conjugated GAPDH Monoclonal antibody (HRP-60004) as loading control.

•

  WB analysis using 67876-1-Ig

  Various lysates were subjected to SDS PAGE followed by western blot with 67876-1-Ig (TMP21 antibody) at dilution of 1:20000 incubated at room temperature for 1.5 hours.

•

  IHC staining of human colon cancer using 67876-1-Ig

  Immunohistochemical analysis of paraffin-embedded human colon cancer tissue slide using 67876-1-Ig (TMP21 antibody) at dilution of 1:2000 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of human colon cancer using 67876-1-Ig

  Immunohistochemical analysis of paraffin-embedded human colon cancer tissue slide using 67876-1-Ig (TMP21 antibody) at dilution of 1:2000 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of mouse brain using 67876-1-Ig

  Immunohistochemical analysis of paraffin-embedded mouse brain tissue slide using 67876-1-Ig (TMP21 antibody) at dilution of 1:2000 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of mouse brain using 67876-1-Ig

  Immunohistochemical analysis of paraffin-embedded mouse brain tissue slide using 67876-1-Ig (TMP21 antibody) at dilution of 1:2000 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IF Staining of HeLa using 67876-1-Ig

  Immunofluorescent analysis of (-20°C Methanol) fixed HeLa cells using TMP21 antibody (67876-1-Ig, Clone: 3B11F9 ) at dilution of 1:800 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L).

•

  FC experiment of HeLa using 67876-1-Ig

  1x10^6 HeLa cells were intracellularly stained with 0.4 ug TMP21 Monoclonal antibody (67876-1-Ig, Clone:3B11F9) and CoraLite®488-Conjugated Goat Anti-Mouse IgG(H+L) (SA00013-1)(red), or 0.4 ug Mouse IgG2b isotype control Mouse McAb (66360-3-Ig, Clone: 11B8C4) (blue). Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C).

---

Tested Applications

• Positive WB detected in: A549 cells, pig liver tissue, HeLa cells, HepG2 cells, Jurkat cells, Raji cells, rat liver tissue, mouse liver tissue
• Positive IHC detected in: human colon cancer tissue, mouse brain tissue; Note: suggested antigen retrieval with TE buffer pH 9.0; (*) Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0
• Positive IF/ICC detected in: HeLa cells
• Positive FC (Intra) detected in: HeLa cells

Recommended dilution

• Western Blot (WB): WB : 1:5000-1:50000
• Immunohistochemistry (IHC): IHC : 1:1000-1:4000
• Immunofluorescence (IF)/ICC: IF/ICC : 1:400-1:1600
• Flow Cytometry (FC) (INTRA): FC (INTRA) : 0.40 ug per 10^6 cells in a 100 µl suspension

It is recommended that this reagent should be titrated in each testing system to obtain optimal results.

Sample-dependent, Check data in validation data gallery.

Product Information

67876-1-Ig targets TMP21 in WB, IHC, IF/ICC, FC (Intra), ELISA applications and shows reactivity with human, mouse, rat, pig samples.

• Tested Reactivity: human, mouse, rat, pig
• Host / Isotype: Mouse / IgG2b
• Class: Monoclonal
• Type: Antibody
• Immunogen: TMP21 fusion protein Ag7516
• Full Name: transmembrane emp24-like trafficking protein 10 (yeast)
• Calculated Molecular Weight: 25 kDa
• Observed Molecular Weight: 21 kDa
• GenBank Accession Number: BC001825
• Gene Symbol: TMED10
• Gene ID (NCBI): 10972
• RRID: AB_2918633
• Conjugate: Unconjugated
• Form: Liquid
• Purification Method: Protein A purification
• Storage Buffer: PBS with 0.02% sodium azide and 50% glycerol pH 7.3.
• Storage Conditions: Store at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20^oC storage. 20ul sizes contain 0.1% BSA.
