Ch-TOG Recombinant antibody

Ch-TOG Uni-rAb^TM Recombinant Antibody for WB, IHC, FC (Intra), ELISA

Host / Isotype

Rabbit / IgG

Reactivity

human

Applications

WB, IHC, FC (Intra), ELISA

Conjugate

Unconjugated

CloneNo.

241546G8

Cat no : 84285-3-RR

Synonyms

CKAP5, TOGp, Cytoskeleton-associated protein 5, Colonic and hepatic tumor overexpressed gene protein, ch TOG

---

Validation Data Gallery

•

  WB analysis using 84285-3-RR

  Various lysates were subjected to SDS PAGE followed by western blot with 84285-3-RR (Ch-TOG antibody) at dilution of 1:10000 incubated at room temperature for 1.5 hours.

•

  IHC staining of mouse cerebellum using 84285-3-RR

  Immunohistochemical analysis of paraffin-embedded mouse cerebellum tissue slide using 84285-3-RR (Ch-TOG antibody) at dilution of 1:1000 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of mouse cerebellum using 84285-3-RR

  Immunohistochemical analysis of paraffin-embedded mouse cerebellum tissue slide using 84285-3-RR (Ch-TOG antibody) at dilution of 1:1000 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  FC experiment of HeLa using 84285-3-RR

  1x10^6 HeLa cells were intracellularly stained with 0.25 ug Ckap5 Recombinant Antibody (84285-3-RR, Clone:241546G8) and APC-Conjugated Goat Anti-Rabbit IgG(H+L)(red), or 0.25 ug Isotype Control (blue). Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C).

•

  FC experiment of A549 using 84285-3-RR

  1x10^6 A549 cells were intracellularly stained with 0.25 ug Ckap5 Recombinant Antibody (84285-3-RR, Clone:241546G8) and APC-Conjugated Goat Anti-Rabbit IgG(H+L)(red), or 0.25 ug Isotype Control (blue). Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C).

•

  Affinity and Kinetic Characterization of 84285-3-RR

  Biolayer interferometry (BLl) kinetic assays of 84285-3-RR against Human Ch-TOG were performed. The affinity constant is 1.05 nM.

---

Tested Applications

• Positive WB detected in: HeLa cells, HepG2 cells, MCF-7 cells, NCCIT cells, SH-SY5Y cells, K-562 cells
• Positive IHC detected in: mouse cerebellum tissue; Note: suggested antigen retrieval with TE buffer pH 9.0; (*) Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0
• Positive FC (Intra) detected in: A549 cells, HeLa cells

Recommended dilution

• Western Blot (WB): WB : 1:5000-1:50000
• Immunohistochemistry (IHC): IHC : 1:500-1:2000
• Flow Cytometry (FC) (INTRA): FC (INTRA) : 0.25 ug per 10^6 cells in a 100 µl suspension

It is recommended that this reagent should be titrated in each testing system to obtain optimal results.

Sample-dependent, Check data in validation data gallery.

Product Information

The immunogen of 84285-3-RR is Ch-TOG Fusion Protein expressed in E. coli.

• Tested Reactivity: human
• Host / Isotype: Rabbit / IgG
• Class: Recombinant
• Type: Antibody
• Immunogen: Ch-TOG fusion protein Ag24875
• Full Name: cytoskeleton associated protein 5
• Observed Molecular Weight: 220 kDa
• GenBank Accession Number: BC120869
• Gene Symbol: Ch-TOG
• Gene ID (NCBI): 9793
• Conjugate: Unconjugated
• Form: Liquid
• Purification Method: Protein A purification
• Storage Buffer: PBS with 0.02% sodium azide and 50% glycerol pH 7.3.
• Storage Conditions: Store at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20^oC storage. 20ul sizes contain 0.1% BSA.

Background Information

Ch-TOG (colonic hepatic tumor-overexpressed gene), also known as XMAP215 or CKAP5, is a microtubule polymerase which can promotes cytoplasmic microtubule nucleation and elongation. Through interacting with Aurora-A and TACC3, it plays a major role in organizing spindle poles.
