Various lysates were subjected to SDS PAGE followed by western blot with 66866-1-Ig (CD81 antibody) at dilution of 1:3000 incubated at room temperature for 1.5 hours.

Immunohistochemical analysis of paraffin-embedded human tonsillitis tissue slide using 66866-1-Ig (CD81 antibody) at dilution of 1:1000 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

Immunohistochemical analysis of paraffin-embedded human tonsillitis tissue slide using 66866-1-Ig (CD81 antibody) at dilution of 1:1000 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

Immunofluorescent analysis of (4% PFA) fixed human tonsillitis tissue using CD81 antibody (66866-1-Ig, Clone: 1G2C6 ) at dilution of 1:1000 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L).

Immunofluorescent analysis of (4% PFA) fixed human tonsillitis tissue using CD81 antibody (66866-1-Ig, Clone: 1G2C6 ) at dilution of 1:1000 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L).

1X10^6 Jurkat cells were surface stained with 0.4 ug Anti-Human CD81 (66866-1-Ig, Clone: 1G2C6) and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L) at dilution 1:1000 (red), or 0.4 ug Control Antibody. Cells were not fixed.

Jurkat cells and Raji cells were subjected to SDS PAGE followed by western blot with 27855-1-AP (CD81 antibody) at dilution of 1:2000 incubated at room temperature for 1.5 hours.

1X10^6 human PBMCs were surface stained with 0.2 ug Anti-Human CD81 (65195-1-Ig, Clone:5A6) and CoraLite®594-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L) at dilution 1:1000 or unstained. Cells were not fixed. Lymphocytes were gated.

1X10^6 human PBMCs were surface stained with 0.2 ug Anti-Human CD81 (65195-1-Ig, Clone:5A6) and CoraLite®594-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L) at dilution 1:1000 or unstained. Cells were not fixed. Lymphocytes were gated.

Various lysates were subjected to SDS PAGE followed by western blot with 66866-1-Ig (CD81 antibody) at dilution of 1:3000 incubated at room temperature for 1.5 hours. This data was developed using the same antibody clone with 66866-1-PBS in a different storage buffer formulation.

Immunohistochemical analysis of paraffin-embedded human tonsillitis tissue slide using 66866-1-Ig (CD81 antibody) at dilution of 1:1000 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0). This data was developed using the same antibody clone with 66866-1-PBS in a different storage buffer formulation.

Immunohistochemical analysis of paraffin-embedded human tonsillitis tissue slide using 66866-1-Ig (CD81 antibody) at dilution of 1:1000 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0). This data was developed using the same antibody clone with 66866-1-PBS in a different storage buffer formulation.

Immunofluorescent analysis of (4% PFA) fixed human tonsillitis tissue using CD81 antibody (66866-1-Ig, Clone: 1G2C6 ) at dilution of 1:1000 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L). This data was developed using the same antibody clone with 66866-1-PBS in a different storage buffer formulation.

Immunofluorescent analysis of (4% PFA) fixed human tonsillitis tissue using CD81 antibody (66866-1-Ig, Clone: 1G2C6 ) at dilution of 1:1000 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L). This data was developed using the same antibody clone with 66866-1-PBS in a different storage buffer formulation.

1X10^6 Jurkat cells were surface stained with 0.4 ug Anti-Human CD81 (66866-1-Ig, Clone: 1G2C6) and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L) at dilution 1:1000 (red), or 0.4 ug Control Antibody. Cells were not fixed. This data was developed using the same antibody clone with 66866-1-PBS in a different storage buffer formulation.

1X10^6 human PBMCs were surface stained with 5 ul CoraLite® Plus 488 Anti-Human CD81 (CL488-65195, Clone:5A6) (red), or Mouse IgG1 Isotype Control (blue). Cells were not fixed. Lymphocytes were gated.

1X10^6 human PBMCs were surface stained with 5 ul CoraLite® Plus 488 Anti-Human CD81 (CL488-65195, Clone:5A6), or Mouse IgG1 Isotype Control. Cells were not fixed. Lymphocytes were gated.

Immunofluorescent analysis of (4% PFA) fixed human tonsillitis tissue using CoraLite®488-conjugated CD81 antibody (CL488-66866, Clone: 1G2C6 ) at dilution of 1:200.

Immunofluorescent analysis of (4% PFA) fixed human tonsillitis tissue using CoraLite®488-conjugated CD81 antibody (CL488-66866, Clone: 1G2C6 ) at dilution of 1:200.

1X10^6 Jurkat cells were stained with 0.2 ug CoraLite®488-conjugated Anti-Human CD81 (CL488-66866, Clone: 1G2C6) (green), or stained with 0.2 ug isotype control (black). Cells were fixed with 90% MeOH.

1X10^6 human PBMCs were surface stained with 5 ul CoraLite® Plus 647 Anti-Human CD81 (CL647-65195, Clone:5A6) (red) or Mouse IgG1 Isotype Control. Cells were not fixed. Lymphocytes were gated.

1X10^6 human PBMCs were surface stained with 5 ul CoraLite® Plus 647 Anti-Human CD81 (CL647-65195, Clone:5A6) or Mouse IgG1 Isotype Control. Cells were not fixed. Lymphocytes were gated.

G65195-1-5C was used to stain Resting PBMC and analyzed with 10x Genomics Gene Expression Flex with Feature Barcodes and Multiplexing kit with Fix-Stain protocol.

G65195-1-5C was used to stain PBMC under 4hr LPS + TI treatment and analyzed with 10x Genomics Gene Expression Flex with Feature Barcodes and Multiplexing kit with Fix-Stain protocol.
