TOM20 Recombinant antibody, PBS Only

TOM20 Uni-rAb^TM Recombinant Antibody for WB, IHC, IF/ICC, Indirect ELISA

Host / Isotype

Rabbit / IgG

Reactivity

human, mouse, rat, pig, chicken, zebrafish

Applications

WB, IHC, IF/ICC, Indirect ELISA

Conjugate

Unconjugated

CloneNo.

1D22

Cat no : 80501-1-PBS

Synonyms

TOMM20, TOMM 20, tom 20, MOM19, MAS20

---

Validation Data Gallery

•

  WB analysis using 80501-1-RR (same clone as 80501-1-PBS)

  Various lysates were subjected to SDS PAGE followed by western blot with 80501-1-RR (TOM20 antibody) at dilution of 1:5000 incubated at room temperature for 1.5 hours. This data was developed using the same antibody clone with 80501-1-PBS in a different storage buffer formulation.

•

  WB analysis of zebrafish using 80501-1-RR (same clone as 80501-1-PBS)

  zebrafish tissue were subjected to SDS PAGE followed by western blot with 80501-1-RR (TOM20 antibody) at dilution of 1:5000 incubated at room temperature for 1.5 hours. This data was developed using the same antibody clone with 80501-1-PBS in a different storage buffer formulation.

•

  IHC staining of human liver using 80501-1-RR (same clone as 80501-1-PBS)

  Immunohistochemical analysis of paraffin-embedded human liver tissue slide using 80501-1-RR (TOM20 antibody) at dilution of 1:200 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0). This data was developed using the same antibody clone with 80501-1-PBS in a different storage buffer formulation.

•

  IHC staining of human liver using 80501-1-RR (same clone as 80501-1-PBS)

  Immunohistochemical analysis of paraffin-embedded human liver tissue slide using 80501-1-RR (TOM20 antibody) at dilution of 1:200 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0). This data was developed using the same antibody clone with 80501-1-PBS in a different storage buffer formulation.

•

  IF Staining of HepG2 using 80501-1-RR (same clone as 80501-1-PBS)

  Immunofluorescent analysis of (4% PFA) fixed HepG2 cells using TOM20 antibody (80501-1-RR, Clone: 1D22 ) at dilution of 1:200 and CoraLite®488-Conjugated Goat Anti-Rabbit IgG(H+L), CL594-Phalloidin (red). This data was developed using the same antibody clone with 80501-1-PBS in a different storage buffer formulation.

•

  Affinity and Kinetic Characterization of 80501-1-RR

  Biolayer interferometry (BLl) kinetic assays of 80501-1-RR against Human TOM20 were performed. The affinity constant is below 1 pM.

---

Product Information

80501-1-PBS targets TOM20 in WB, IHC, IF/ICC, Indirect ELISA applications and shows reactivity with human, mouse, rat, pig, chicken, zebrafish samples.

• Tested Reactivity: human, mouse, rat, pig, chicken, zebrafish
• Host / Isotype: Rabbit / IgG
• Class: Recombinant
• Type: Antibody
• Immunogen: TOM20 fusion protein Ag2378
• Full Name: translocase of outer mitochondrial membrane 20 homolog (yeast)
• Calculated Molecular Weight: 145 aa, 16 kDa
• Observed Molecular Weight: 16 kDa
• GenBank Accession Number: BC000882
• Gene Symbol: TOM20
• Gene ID (NCBI): 9804
• Conjugate: Unconjugated
• Form: Liquid
• Purification Method: Protein A purification
• Storage Buffer: PBS Only
• Storage Conditions: Store at -80°C.

Background Information

TOM20, also named as KIAA0016, belongs to the Tom20 family. It is a central component of the receptor complex responsible for the recognition and translocation of cytosolically synthesized mitochondrial preproteins. Together with TOM22, TOM20 functions as the transit peptide receptor at the surface of the mitochondrion outer membrane and facilitates the movement of preproteins into the TOM40 translocation pore. TOM20 is characterized as major docking receptors to mediate the recognition by different mechanisms.
